Aluminum Glass Railing
Premium architectural guardrail systems combining high-strength aluminum profiles with tempered glass panels. Designed for modern balcony, staircase, and terrace applications, these railings provide safety without compromising views or aesthetic appeal.
Aluminum Components
Alloy: 6063-T5/T6 extruded aluminum
Profile Thickness: 2.5-4mm (structural members)
Surface Treatments:
Anodized (25μm, AA-M12-C22)
Powder Coated (80μm DFT, 200+ RAL colors)
Wood Grain Finish (thermal transfer)eal.
Glass Specifications
Type: Tempered (EN 12150) or Laminated (EN 14449)
Thickness Options: 10mm/12mm/15mm/19mm
Edgework: Seamed/polished edges (ISO 12543)
Performance Data
1. Structural Safety:
Horizontal Load: ≥1.5kN/m (EN 1991-1-1)
Impact Resistance: 50J (BS 6180)
Deflection Limit: L/175 under load
Environmental:
Corrosion Resistance: C4 (ISO 9224)
Temperature Range: -40°C to +80°C
UV Stability: ΔE<3 (5000hr QUV)
Technical Advantages
Safety: Exceeds international guardrail standards
Durability: Maintenance-free aluminum construction
Aesthetics: Slim 50mm sightlines
Customization: 200+ finish options
